details
Gross weight
0.44 kg
Net weight
0.37 kg
EAN
5702423148653
Amb. Temp. Note
80 °C/176 °F for max 120 min
Ambient temperature range [°C] [Max]
65 °C
Ambient temperature range [°C] [Min]
-40 °C
Ambient temperature range [°F] [Max]
150 °F
Ambient temperature range [°F] [Min]
-40 °F
Approval
BV
CCC
CE
DNV
EAC
GL
LVD
PZH
RINA
RMRS
RoHS China
c UL us UL353, CS C22.2
c UL us UL873, CS C22.2
LLC CDC EURO-TYSK
Cap. tube length fraction [in]
78 3/4 in
Capillary tube length [mm]
2000 mm
Charge type
Adsorption
Contact function
SPDT
Contact rating
AC15=10 A, 400 V
AC1=16 A, 400 V
AC3=16 A, 400 V
DC13=12 W, 220 V
LR=112 A, 400 V
Diff. @ Max. range setting [K] [Max]
15 K
Diff. @ Max. range setting [K] [Min]
5 K
Diff. @ Max. range setting[°C] [Max]
15 °C
Diff. @ Max. range setting[°C] [Min]
5 °C
Diff. @ Min. range setting [K] [Max]
15 K
Diff. @ Min. range setting [K] [Min]
5 K
Diff. @ Min. range setting[°C] [Max]
15 °C
Diff. @ Min. range setting[°C] [Min]
5 °C
Differential type
Adjustable
Electrical connection
Rubber cable gland
Electrical connection size
6-14 mm
Electrical spec. standard
EN 60947-5
EN 60947 electrical properties
Pollution degree: 3
Rated impulse voltage: 4 kV
